Ultimate Power Upgrade BIG 3 - Jeep XJ/MJ

K SuspensionSKU: KS-UPE-1

Year: 87-90 (Renix)
Fuse Size: 150A
Battery Terminals: No

Usually ships in 1-5 days.


Say Hello to the Ultimate Power +/- kit for your battery cable needs. Made from 2AWG Welding Wire Cables. MADE IN THE USA!

Unlike some that only sell you 3 wires for your Battery, Alternator, and main Ground, our kit does a complete upgrade over your factory wiring.

​Each kit is hand made right in Nampa, ID.

Kit includes 6 main wire upgrades for your needs:

91-01 Jeep XJ/MJ 4.0L


  • Battery + to Starter
  • Battery + to PDC
  • Alternator to PDC with ANL Fuse + Holder (plus spare fuse!)


  • Battery - to Chassis
  • ​Battery - to Block
  • Head to Firewall

87-90 Jeep XJ/MJ 4.0L


  • Batt to Starter
  • Batt to Starer Motor/Distribution
  • Alternator to PDC (included 2 extra lugs and heat shrink to add if you have higher output Alternator installed)


  • Batt to Engine Block
  • Batt to Fenderwell (chassis)
  • Head to Firewall

Our wiring is a thick, 2 awg welding wire; Fine Strands for best conductivity and flow of energy.

Each terminal lug is crimped on with with hydraulic compression pliers for a secure connection that won't come loose!

All cables are marked for ease of installation.

Don't know which fuse rating to get? No problem!

Find your alternator output (i.e: 90A) Add 30% and round up!

For example; 90 + 30% = 117, round up = 150A ANL Fuse

​You won't have any loss of power with this upgrade.

Marine grade glue-lined heat shrink for a good cover that won't crack or break over time and is resistant to cuts/scratches.

Cable lugs are Zinc Plated Copper, which acts as a shield to inhibit oxidation of the ends.

As always, Free Shipping in the USA, Additional shipping fee to International Purchases. And our cables come with a LIFETIME Guarantee on the crimps. If they ever come apart at the lug, we fix or replace it for free!

*​Professional installation is recommended, any improper installation leading to premature failure of any part will not be covered under any type of warranty*
